Description
Technical features
BETA DETECTOR
2.000 mm2 large sensitive silicon diode
GAMMA DETECTOR
1,5 x 1,5” LaBr3 (Ce) crystal
ENERGY RANGE
Beta: 80 keV to 3 MeV
Gamma: 50 keV to 2 MeV
SAMPLING RATE
SA200: 17 m3/h
SA210: 3 m3/h
TEMPERATURE RANGE
From -30°C to +50°C
POWER SUPPLY
Mains single phase 220 V or 110 V,
optional batteries for SA210 version
COMMUNICATION
Embedded PC connection (Ethernet)
Optional: GPRS, GSM, 3G/4G, Satellite
DIMENSIONS AND WEIGHT*
SA200: 206 x 133 x 90 cm – 250 kg
SA210: 115 x 85 x 65 cm – 200 kg
* depends on delivered configuration
Applications
Nationwide monitoring
Ring monitoring for nuclear facilities
Area monitoring
